Galvanised Metal Mesh Lath - 2500 X 700mm

Product Name:  Galvanized Metal Mesh Lath / Metal Lathing / Dimpled Self-Furring Galvanized Steel Lath

Item Code:  Smart Craftsmen-Lathsheet

Raw Material: Galvanised steel or Stainless Steel.

Package: Bundles & Pallets

Length: 2.0-3.0 Metre or Customized.

Place of Origin:  Hebei, China.

Standards: G60 Galvanized Steel and SS garde of 1.4301 Stainless Steel or others.

Products Details

Galvanized Metal Mesh Lath / Metal Lathing / Dimpled Self-Furring Galvanized Steel Lath is used as a substrate for gypsum plaster or for Portland cement plaster stucco on exterior or interior walls. Manufactured with approximately 1/4" deep dimples that are spaced every 1-1/2" o.c. over the entire 27" x 96" rectangular sheet: this pattern holds lath away from solid surfaces like cement board, masonry, old surfaces, etc... & enables the plaster to penetrate fully bond. To maintain the designed furring characteristics, fasteners must be applied in the dimple cavity.

Expanded Metal Lathing is mainly used as a key for internal and external plaster when applied on suspended ceilings and walls. It is also suitable for encasing steel columns and beams, assisting in the protection from fire. In external applications and where there is regular exposure to moisture, heavy condensation, persistent damp or concern that drying out times may be extended, stainless steel should be used.


CodeWidth(mm)Length(mm)Thickness(mm)Square Metre m2Packing
10 PCS/Bundle, 250 PCS/ Pallet
Stainless Steel 1.4301
SEML27x96700mm2438mm1/8”(3.2mm)1.7510 PCS/Bundle, 250 PCS/ Pallet
NoteOther thickness, Width, Length and Material is also available.
