Product Name: Hot Dipped Galvanized Iron Wire
Item Code: Smart Craftsmen-HDG Wire
Surface Treatment: Electro Galvanized.
Raw Material: SAE1006 SAE1008 Q195 Q235 or Others.
Tensile Strength: 330-550MPA
Package: Customize.
Place of Origin: Hebei, China.
Loading Port: Tianjin Port
Galvanized Iron Wire is designed to prevent rusting and shiny silver in color. It is solid,durable and extremely versatile, it is widely used by landscapers, building,weaving the hardware cloth and mesh. Galvanized wire is divided into hot dipped galvanized wire and electro-galvanized wire (cold galvanized wire). Galvanized wire has good flexibility and toughness. with zinc coating thickness, corrosion resistance and other characteristics. Hot-dipped galvanized iron wire is made with choice low carbon steel wire, through wire drawing, acid washing and rust removing, annealing and coiling.
Electro galvanized iron wire is made with choice mild steel, through wire drawing, wire galvanizing and other processes. Electro galvanized iron wire has the characteristics of thick zinc coating, good corrosion resistance, firm zinc coating, etc.
Products Features
Name | Hot Dipped Galvanized Wire | Electro Galvanized | |
Zinc Coated | 45-366g / m2 | 10-18g / m2 | |
Wire Gauge | BWG8-26# | AWG8-26# | SWG8-26# |
Wire Diameter | 4.00mm-0.46mm | 4.00mm-0.46mm | 4.00mm-0.46mm |
Raw Material | Q 195 or As your request. | ||
Tensile Strength | 350-550N / mm2 |
Wire Gauge Size | SWG(mm) | BWG(mm) | BG(mm) |
8 | 4.06 | 4.19 | 3.988 |
9 | 3.66 | 3.76 | 3.551 |
10 | 3.25 | 3.40 | 3.175 |
11 | 2.95 | 3.05 | 2.827 |
12 | 2.64 | 2.77 | 2.517 |
13 | 2.34 | 2.41 | 2.240 |
14 | 2.03 | 2.11 | 1.994 |
15 | 1.83 | 1.83 | 1.775 |
16 | 1.63 | 1.65 | 1.588 |
17 | 1.42 | 1.47 | 1.412 |
18 | 1.22 | 1.25 | 1.257 |
19 | 1.02 | 1.07 | 1.118 |
20 | 0.91 | 0.89 | 0.996 |
21 | 0.81 | 0.813 | 0.887 |
22 | 0.71 | 0.711 | 0.749 |
23 | 0.61 | 0.635 | 0.707 |
24 | 0.56 | 0.559 | 0.629 |
25 | 0.51 | 0.508 | 0.560 |
26 | 0.46 | 0.457 | 0.498 |
